Technical Information and Specifications.

b.a.d.Vision Wearable Action Cameras

badVision Wearable Video Camera
badVision Wearable action Camera
badVision Wearable Action Camera

badVision Cyclops Camera

Image Sensor Pixels:  1/3.2” 5MP, CMOS SENSOR;Still image:  5MP
Image Resolution:  2048 x1536
Digital VideoRecording Rate:  Up to 30 fps @HD 720p
Video Resolution:  1280 x 720 HD 720p
Lens Angle:  135 degree full field of view
Lens:  3G 1P fixed lens
Lens Aperture:  f/3.2 f=3,02mm
Lens Focus:  1.2M to infinity
Shutter Speed:  Still: 1/8 to 1/4000 seconds
Sensitivity:  Auto ISO
White Balance:  Automatic
Audio:  Built-in Microphone w/Wind Guard
Memory:  Supports max 32gb Micro SD Card - Quality 10X
Support System:  Windows 7/ XP/Vista and Mac 10.4 or above
Interface:  USB 2.0
Power:  3.7V 1200mAh
Battery:  Lithium Rechargeable
Battery Performance:  Video up to 4 hrs.

Notes:  No Software required to download
             2 lens – Mirrored Lens Polarized 100% UV
             Anti-fog lens
             Uses:  Ski/Moto/Tactical


badVision HD HOTSPOT​


5.0 Mage 720P with 170 degree wide-angle

Memory:  support TFcard 2GB – 32GB
Resolution:   1280*720 (HD), AVI
Effective pixels:   5 mega pixels
Recording speed: 30fps
User friendly operation and buttons for easy control.
TV-out function makes network life more colorful.
Battery:   350MAH Li-polymer battery
Battery:  5v DC/350MA
USB:  2.O
Power consumption:   <0.59W
Work temp:   -5degree C -40 degree C
Storage temp:  -20 degree C  -80 degree C
Player:   Windows media Real Player, Storm codec, QuickTime
Menu language:  English
Operation system:  Win98, Winme, Win XP, Win2000, Windows Vista, Windows7
Accessories:   glasses bag, glass case, glasses cloth, USB cable, Manual, remote control
Color Lens Options: clear, red, yellow, blue, grey, green



badVision HD SPARK.​


5.0Megapixel 1/2.5HD CMOS Sensor---Max 12.0Megapixel
HD Video Resolution: HD1080P:  1920 x 1080P @30fps;     1440 x 1080(30fps); 1280 x 720(60fps),1280 x 720 (30fps)
Video format:  H.264 /photo Codec:  JPEG
Image Resolution: 12 M/8 M/5 M (option)
140° wide angle, 20 Meter Waterproof HD Camera
Integrated laser pointer for alignment, also includes white LED lights to assist with mild darkness recording.
Built in with an integrated micro-phone, Digital Video Stabilization.
Memory slot for Micro-SD card up to 32 GB (class 6)
Battery Power:  Rechargeable lithium-ion battery 900MAH
3 hours continual working.

USD2.0 high-speed video transfer, AVI video formatting, Supports HDMI and TV-out as well as Mac and PC.your service. Feel free to change the image.
